WATER TREATMENT PLANTS

Water is the most important and necessity element in human life. Approximately 70% of the human body, water is found in the cells. The source of all body fluids including blood, lymph, saliva, digestive enzymes, urines etc. is the pure drinking water. Water is the regulator of all body functions. It is the main source for transporting energy to every cell in the body. The brain is also made up of 80% of water, severe dehydration may lead to mental derangement, inability to think clearly.

THE 8 TYPES OF WATER ARE:

  • Non-potable
  • Potable (drinkable) water
  • Water for injection (WFI)
  • Sterile water for injection
  • LUSP sterile water for inhalation
  • USP bacteriostatic water for injecon
  • USP sterile water for irrigation
Slide 1 Slide 2

PRE-TREATMENT

Pre-treatment plays very important role in efficient and safe operation of the purified water generation system. The pre-treatment units are modular and are designed according to the raw water characteristics.

Media Filtraon, Soener & Ultra filtraon Plant

    All pre-engineered standard packaged plants have FRP vessels with automatic operation facility. Manually operated filters can be provided on request. Automatic disc filtration in lieu of media filter is also available as an option.

    Softeners are made using uniform particle size IX resin which gives highest regeneration efficiency and lowest outlet hardness. As a standard feature the Soeners are supplied with automatic operation facility. All UF plants are fully automatic and can be designed as dead-end plant operation or with continuous bleed depending on feed water characteristics.

RO-EDI

    Ibargus Engineering Designs & offers standard packaged RO-EDI systems from 250 lph to 50,000 lph capacities for Various applications. Customized and larger capacities RO Plants are also available on request.

    Standard package systems include chemical dosing stations, 5 micron cartridge filters and RO Block. The RO Block typically has two passes in which the Pass 1 permeate is treated through Pass 2 RO. The RO Membranes are housed in electro polished SS316L RO tubes fitted with SS316L piping, valves and fittings. The RO permeate is purified further by an EDI unit to achieve PW water quality. An independent skid mounted CIP System is provided for RO cleaning and the hot water RO also includes a heat sanitisation system; it has an option of heating either by steam or by electricity.
